New Holland Tractors

From the outset, New Holland developed the T4LP tractor to meet two diverse end user demands. The first are operators looking for a low height tractor for use in applications to include fruit production and viticulture in steep terrain. The second are operators working in mountainous areas where a low centre of gravity, good rear lift capacity and wide track stability are paramount. Offering good power to weight ratios, a low centre of gravity and a specification choice to suit specific demands, T4LP tractors make a versatile small tractor choice. With New Holland, versatility comes as standard.

Description

COMPACT AND AGILE
Light and compact, T4LP tractors are designed to offer the agility you would expect from this class of tractor. Thanks to a 55 degree turn angle, these 4WD drive tractors can deliver an un-braked turn radius as low as 4,000mm.In extreme terrain the standard front axle oscillation of 8 degrees can be increased to a maximum of 11 degrees for greater ground contour following.

New Holland Engine*	F5C	F5C	NEF	NEF
No. of cylinders / Capacity / Valves / Emissions Level	4 / 3200 / 2 / Tier 3	4 / 3200 / 2 / Tier 3	4 / 4500 / 2 / Tier 3	4 / 4500 / 2 / Tier 3
Turbocharged Intercooler	Standard	Standard	Standard	Standard
Approved biodiesel Blend	B100**	B100**	B100**	B100**
Rated Engine Power ISO TR14396 – ECE R120 @ 2300rpm [kW/hp(CV)]	57/78	65/88	71/97	78/106
Torque reserve (%)	39	30	35	31
Max. Torque ISO TR14396 (Nm)	330@1250rpm	352@1250rpm	398@1300rpm	425@1300rpm
Horizontal Exhaust / Vertical exhaust (Cab only)	Standard/ Optional	Standard/ Optional	Standard/ Optional	Standard/ Optional
Internal EGR	Standard	Standard	Standard	Standard
Fuel tank capacity (L)	98	98	98
